Intel Iris Xe Graphics capability requires system to be configured with dual-channel memory. On the system with single-channel memory, Intel Iris Xe Graphics will function as Intel UHD Graphics.
Operating System : Windows 11 Pro
Graphics
Graphics
Type
Memory
Key Features
Intel UHD Graphics
Integrated
Shared
DirectX 12
Notes:
Intel Iris Xe Graphics capability requires system to be configured with dual-channel memory. On the system with single-channel memory, Intel Iris Xe Graphics will function as Intel UHD Graphics.
Monitor Support
Supports up to 2 independent displays (native display and 1 external monitor via HDMI) • HDMI supports up to 4K 30Hz
Chipset
Chipset
Intel SoC (System on Chip) platform
Memory
Max Memory
Up to 12GB (4GB soldered + 8GB SO-DIMM) DDR4-3200 offering
Up to 16GB (8GB soldered + 8GB SO-DIMM) DDR4-3200 offering
Memory Slots
One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
Memory Type
DDR4-3200
Notes:
The max memory is based on the test results with current Lenovo memory offerings. The system may support more memory as the technology develops.
Storage
Storage Support
Models with 38Wh battery: up to two drives, 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB
Models with 45Wh battery: one drive, 1x M.2 SSD • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB
Storage Slot
Models with 38Wh battery: one 2.5" drive slot + one M.2 slot • One 2.5" SATA HDD slot • One M.2 2280 PCIe 3.0 x4 slot
Models with 45Wh battery: one M.2 slot • One M.2 2280 PCIe 3.0 x4 slot
Storage Type
Disk Type
Interface
RPM
2.5" SATA HDD
SATA 6Gb/s
5.4K
M.2 2242 SSD
PCIe NVMe, PCIe 3.0 x4
-
M.2 2280 SSD
PCIe NVMe, PCIe 3.0 x4
-
Notes:
The storage capacity supported is based on the test results with current Lenovo storage offerings. The system may support larger storage as the technology develops.
Removable Storage
Optical
USB external DVD burner (DVD±RW), 9.5mm high
None
Card Reader
4-in-1 card reader (SD, SDHC, SDXC, MMC)
Multi-Media
Audio Chip
High Definition (HD) Audio, Realtek ALC3287 codec
Speakers
Stereo speakers, 1.5W x2, Dolby Audio
Microphone
Dual-microphone array
Camera
HD 720p, with privacy shutter, fixed focus
Battery
Battery
Integrated Li-Polymer 38Wh battery, supports Rapid Charge (charge up to 80% in 1hr)
Integrated Li-Polymer 45Wh battery, supports Rapid Charge (charge up to 80% in 1hr)
Max Battery Life[1]
Models with 38Wh battery: MobileMark 2018: 5.5 hr Local video (1080p) playback150nits: 8.5 hr
Models with 45Wh battery: MobileMark 2018: 7.5 hr Local video (1080p) playback150nits: 12 hr
Notes:
All battery life claims are approximate maximum and based on results using the MobileMark 2014, MobileMark 2018, JEITA 2.0, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary and depends on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use.
Power Adapter
Power Adapter
65W round tip (2-pin, wall-mount) AC adapter, 100-240V, 50-60Hz
California Electronic Waste Recycling Fee In California, per state law, Lenovo charges an electronic waste recycling fee on this covered device at the time of sale of the product. For more information, go to
Input Device
Keyboard
6-row, multimedia Fn keys, numeric keypad
Keyboard Backlight
LED backlight
Non-backlight
Touchpad
Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 69 x 104 mm (2.72 x 4.09 inches)
Mechanical
Dimensions (WxDxH)
359.2 x 236.5 x 19.9 mm (14.14 x 9.31 x 0.78 inches)
Weight
Starting at 1.65 kg (3.63 lbs)
Case Color
Abyss blue
Arctic grey
Galaxy blue
Sand
Surface Treatment
IMR (in-mold decoration by roller)
Case Material
PC-ABS (top), PC-ABS (bottom)
PC-ABS (top), speckled resin (bottom)
Notes:
The system dimensions and weight vary depending on configurations.
Connectivity
Network
Ethernet
No onboard Ethernet
WLAN + Bluetooth
802.11ac 2x2 Wi-Fi + Bluetooth 5.0, M.2 card
Wi-Fi 6, 802.11ax 2x2 Wi-Fi + Bluetooth 5.1, M.2 card
Notes:
Bluetooth 5.2 is hardware ready but may run at a lower version due to OS limitation
Ports
Standard Ports
1x USB 2.0
1x USB 3.2 Gen 1
1x USB-C 3.2 Gen 1 (support data transfer only)
1x HDMI 1.4b
1x Card reader
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
Notes:
The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed. USB 2.0: 480 Mbit/s; USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s; USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s; USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s; Thunderbolt™ 3/4: 40 Gbit/s
Security & Privacy
Security
Security Chip
Firmware TPM 2.0 integrated in SoC
Fingerprint Reader
Touch style fingerprint reader integrated in power button
No fingerprint reader
BIOS Security
Administrator password
Power-on password
Hard disk password
Other Security
Camera privacy shutter
Service
Environmental
Operating Environment
Temperature
At altitudes up to 2438 m (8,000 ft) - Operating: 5°C to 35°C (41°F to 95°F) - Storage: 5°C to 43°C (41°F to 109°F)
At altitudes above 2438 m (8,000 ft) - Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F)
Humidity
Operating: 8% to 95% at wet-bulb temperature 23°C (73°F)
Storage: 5% to 95% at wet-bulb temperature 27°C (81°F)
Altitude
Maximum altitude (without pressurization): 3048 m (10,000 ft)
Notes:
When you charge the battery, its temperature must be no lower than 10°C (50°F).
Green Certifications
ErP Lot 3
RoHS compliant
Feature with means that only one offering listed under the feature is configured on selected models.
Feature with means that one or more offerings listed under the feature could be configured on selected models.
