LENOVO LOQ 15IRH8 82XV0083AX-Intel Core i7-13620H-NVIDIA GeForce RTX 4050 6GB-8GB DDR5-5200-512GB SSD M.2-15.6 FHD 1920x1080 IPS 144Hz

LOQ 15IRH8

Model : 82XV0083AX

PERFORMANCE

Processor

Intel Core i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB

Graphics

NVIDIA GeForce RTX 4050 6GB GDDR6, Boost Clock 2370MHz, TGP 95W

Chipset

Intel SoC Platform

Memory

1x 8GB SO-DIMM DDR5-5200

Memory Slots

Two DDR5 SO-DIMM slots, dual-channel capable

Max Memory

Up to 32GB DDR5-5200

Storage

512GB SSD M.2 2242 PCIe 4.0x4 NVMe

Storage Support

Up to two drives, 2x M.2 SSD

• M.2 2242 SSD up to 1TB

Storage Slot

Two M.2 slots

• One M.2 2242 PCIe 4.0 x4 slot

• One M.2 2280 PCIe 4.0 x4 slot

Card Reader

None

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek ALC3287 codec

Speakers

Stereo speakers, 2W x2, optimized with Nahimic Gaming Audio

Camera

FHD 1080p with E-shutter

Microphone

2x, Array

Battery

Integrated 60Wh

Power Adapter

170W Slim Tip (3-pin)

Special Features

AI Chip: LA1

DESIGN

Display[1]

15.6" FHD (1920x1080) IPS 350nits Anti-glare, 45% NTSC, 144Hz, G-SYNC

Touchscreen

None

Color Calibration

None

Keyboard

4-Zone RGB Backlit, Arabic

Case Color

Storm Grey

Surface Treatment

Painting

Case Material

PC-ABS (Top), PC-ABS (Bottom)

Dimensions (WxDxH)

359.6 x 264.8 x 22.1-25.2 mm (14.16 x 10.43 x 0.87-0.99 inches)

Weight

Starting at 2.4 kg (5.29 lbs)

SOFTWARE

Operating System

None

Bundled Software

None

CONNECTIVITY

Ethernet

100/1000M (RJ-45)

WLAN + Bluetooth

Wi-Fi 6, 11ax 2x2 + BT5.1

Standard Ports

1x USB 3.2 Gen 1

2x USB 3.2 Gen 2

1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 140W and DisplayPort 1.4)

1x HDMI 2.1, up to 8K/60Hz

1x Ethernet (RJ-45)

1x Headphone / microphone combo jack (3.5mm)

1x Power connector

Docking

Various docking solutions supported via USB-C.

For more compatible docking solutions, please visit <a href="https://smartfind.lenovo.com/accessories/#/search?categoryL1Name=Docking&categoryL2Names&pageIndex=1&pageSize=40&query=82XV" target="_blank">

<u>Docking for LOQ 15IRH8</u></a>

SECURITY & PRIVACY

Security Chip

Firmware TPM 2.0 Enabled

Fingerprint Reader

None

Other Security

E-shutter

MANAGEABILITY

SERVICE

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

2Y Courier/Carry-in upgrade from 1Y Courier/Carry-in

ACCESSORIES

Bundled Accessories

Lenovo LOQ M100 RGB Mouse

CERTIFICATIONS

Green Certifications

ErP Lot 3

RoHS compliant

Note

1. IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
